Rinnai Australia - 45 - Solar Split Systems Operating / Installation Manual - Version 9 - 21/11/12
Stainless Steel Gas Boosted with USKIT1A
Items Supplied with Cylinder
Items Supplied in USKIT1A
1
1
PTR Valve
11004784
1
Adaptor ¾ R to ½ Rp
19801004
3
2
T ¾ Rp
19001011
8
1
Cold Inlet Copper T
11603921
4
2
Nipple R ¾
17201005
9
1
G ¾ (comp) x R ¾ Union
32201713
5
1
Adaptor R ¾ to G ¾ (flexi)
17201006
6
2
Fibre Washer ¾
17401008
11
1
Pump & Controller Assembly 39001739
includes:
t 2 x ½” Kinco nut & olive
t ow control valve 11001033
t non return valve 27801713
t Temperature sensor lead 31002710
t Pump 30001754
Control Box 31002703
7
1
Insulated Flexi Pipe
1080 mm
11601069
10
1
Temperature Sensor
Sheath 250 mm
10204721
12
1
Temperature Sensor with 2 m lead
Part of Pump and Controller Assembly
(39001735), but shown separately
for clarity in diagrams 31002710
13
1
Elbow ¾ Rp x ¾ G flexi
21201012
-
6
Screws
22601048
-
1
Operation and
Installation Manual
15401021
-
1
Warranty booklet
15401041
14
2
Gas Booster Mounting Brackets
1 x tabs bent
26601098
1 x tabs unbent 26601096
-
1
STC form
15401023
8
Screws
22601048
1
Gas Booster Mounting
Template (Prestige Gas)
15401040
t
To Next Page
