Glass Lined Electric Boosted Systems with USKIT1A
Items Supplied with Cylinder
Items Supplied in USKIT1A
1
1
PTR Valve
SE160,SE200 92501190
SE315 92501192
1
Adaptor R¾ x Rp½
8
1
Cold Inlet Copper T
11603921
3
3
Adaptor R¾ x Rp¾
9
1
G3/4 (Comp) x R ¾ union
32201713
11
1
Pump & Controller Assembly 39001739
includes:
t 2 x ½” Kinco nut & olive
t ow control valve 11001033
t non return valve 27801713
t Temperature sensor lead 31002710
t
t Pump 30001754
Control Box 31002703
12
1
Temperature Sensor with 2 m lead
Part of Pump and Controller Assembly
(39001735), but shown separately
for clarity in diagrams
31002710
-
6
Screws
22601048
-
1
Operation and
Installation Manual
15401021
-
1 Warranty booklet
15401041
-
1 STC form
15401023
