Operator Manual Rev 2.00
Page 9 AXLE-612-200
USB Operation
1.9 USB Operation
When using the USB drive provided by Rinstrum you will want to copy 2 files
from the folder named “Data Store”. (See setting up Farm database for the first
time) The harvest.csv & trucks.csv need to be moved to the ROOT directory of
the USB drive.
There are 3 options to select once the USB drive has been detected by the
console. (Make sure you start at the idle screen to read USB)
TO USB
This means you will send the log.csv file to the USB drive. (This creates a
copy only – the original log file will remain on the console)
FROM USB
This means you will duplicate the files from the USB drive. If you have
modified the truck.csv file or the harvest.csv file then they will overwrite
your truck configuration and your farm & field configuration.
EJECT USB
This will prepare the console for the USB drive to be removed.
