Operator Manual Rev 2.00
Page 10 AXLE-612-200
Selecting Trucks
2.0 Selecting Trucks
Select a Truck ID - Short Press of [F1] (TRUCK KEY)
A short press of the [F1] key will allow the user to select the desired truck from
the truck list. The <UP> and <DOWN> keys will then step through the list of
trucks in the truck database. Press [OK] to select that truck.
The second option is to use a remote key fob. If using the key fob make sure
that your pre-set data is configured. (ONE PASS or TWO PASS - see below.)
Press the button on your key fob once or until the GREEN Lights illuminate
and then proceed across the scale at a steady 3 m.p.h.
TWO PASS INBOUND ONE PASS TWO PASS OUTBOUND
These are the 3 types of screens you will see on the display when the key fob
has been activated.
ONE.PASS: Empty weight of truck is specified. Truck is weighed full for each
weighment.
TWO.PASS: Weight of truck is not specified requiring truck to be weighed twice.
In & then out.
