Operator Manual Rev 2.00
Page 13 AXLE-612-200
2.5 Loading paper
The TG2460 receipt printer uses thermal paper (PN# A10066) which can be
loaded by removing the outer white paper ring.
2.6 Adjusting the printer
To ensure optimal operation you will want to make sure the cover spring is
adjusted for maximum tension. See below.
NO TENSION MAX TENSION
To prevent paper jamming and printer faults move the spring to the MAX
TENSION.
The spring can be moved using a small pair of needlenose or a small
screwdriver.
