Rinstrum AxleweighR R423 User Manual

Operator Manual Rev 2.00
Page 8 AXLE-612-200
Traffic Lights
1.8 Traffic Lights
While at Zero & stable weight the traffic lights should both be off. There are
various conditions that will activate the lights. If there are errors the RED light will
activate. See table below.
NO LIGHTS/ IDLE GREEN LIGHTS LIT
TRAFFIC LIGHT STATUS
Code
Description
Possible cause
RED
SOLID ON
ERROR – CHECK SCALE DISPLAY FOR
ERROR CODE
RED
5 SEC THEN OFF
NORMAL OPERATION (TICKET PRINTS)
GREEN
SOLID ON
CLICKER PRESS DETECTED/ TRUCK IN
PROCESS OF WEIGHING/ WEIGHT
DETECTED OVER 1000 LBS
BOTH
OFF
GREEN & RED
ARE BOTH OFF
SCALE IS IN IDLE MODE/ NO POWER TO
SCALE
