Operator Manual Rev 1.21
Page 8 003X-607-121
3.4. Annunciators
Symbol Name Description
ZERO
Visible when the gross reading is
within ± ¼ of a division of true zero.
NET
Visible when the displayed reading
represents Net weight.
MOTION
Visible when the displayed reading
is not stable.
OVER
Visible when check weighing is
enabled and the weight is above
the target weight.
UNDER
Visible when check weighing is
enabled and the weight is below the
target weight.
PASS
Visible when check weighing is
enabled and the weight is between
the target weights.
1 RANGE 1
Visible when dual range is enabled
and range 1 is active. (K306 only.)
2 RANGE 2
Visible when dual range is enabled
and range 2 is active. (K306 only.)
ZERO
BAND
Visible when the displayed weight is
within the zero 'dead' band setting.
(The zero band symbol shows near
the top right corner of the display.)
HOLD
Visible when the displayed reading
is held.
LOW
BATTERY
Visible when battery voltage is too
low and batteries need replacing or
recharging. (The low battery
symbol shows in the top right
corner of the display.)
