Rinstrum X320 User Manual

Operator Manual Rev 1.21
003X-607-121 Page 17
6.2. Setup and Calibration Errors
Error Description Resolution
The instrument may be in
Safe Setup and an item that
needs Full Setup has been
selected for editing.
Access Full Setup to edit
the item.
(ENTRY)
(DENIED)
When accessing setup,
more than three attempts
have been made with the
incorrect passcode.
Turn the instrument off.
When the instrument is
turned back on, enter the
correct passcode to access
setup.
(LIN.PT)
(LO)
An attempt has been made
to place a linearisation point
below zero.
Incorrect linearisation point
entered (must be between
zero and full scale).
(PT.TOO)
(CLOSE)
An attempt has been made
to place a calibration point
too close to an existing
calibration point.
Re-enter the calibration
point. Points must be
spaced by at least 2% of
full scale from each other.
(RES)
(LO)
The scale build is configured
for less than 100
graduations.
Check the resolution
(count-by) and capacity
settings.
(RES)
(HIGH)
The scale build is configured
for more than 30,000
graduations.
(K307: 60,000 graduations)
Check the resolution
(count-by) and capacity
settings.
(SPAN)
(LO)
The load cell signal range
(span) is too small for these
settings.
Incorrect span weight
entered (must be between
zero and full scale). Scale
wiring incorrect. Wrong
load cell capacity (too
large). Wrong or no
calibration weight added to
scale.
(SPAN)
(HI)
The load cell signal range
(span) is too large for these
settings.
Incorrect span weight
entered (must be between
zero and full scale). Scale
wiring incorrect. Load cell
capacity too small for
application.
(ZERO)
(LO)
An attempt has been made
to calibrate zero below
-2mV/V.
Scale wiring incorrect.
(ZERO)
(HI)
An attempt has been made
to calibrate zero above
+2mV/V.
Remove all weight from
scale. Scale wiring
incorrect.
