18 Rittal Blue e+ fan-and-filter unit assembly and operating instructions
EN
Technical specifications
Unit Model No.
Fan-and-filter unit RAL7035 3243.700 3243.710
Fan-and-filter unit RAL9005 3243.708 3243.718
EMC fan-and-filter unit RAL7035 3243.800 3243.810
Electrical specifications
Rated operating voltage
V
Hz
230, 1~,
50/60
115, 1~,
50/60
Rated current max. A 0.39/0.47 0.81/0.90
Tolerance rated operating voltage % ±10
Power consumption W 77.7/106.4 78.7/102.8
Pre-fuse T A 4 6
Motor circuit-breaker A –
Air throughputs (further information can be found in the characteristic curves on the Rittal homepage)
Unimpeded airflow with chopped-fibre filter m³/h 540/590
With outlet filter including chopped-fibre filter m³/h 444/498
Unimpeded airflow with pleated filter m³/h 625/716
With outlet filter including pleated filter m³/h 565/645
Other
Weight (net) kg 3.12
Fan Diagonal, capacitor motor
Fan bearing Ball bearing
Noise pressure level dB (A) 62/65 62/65
Operating temperature °C -30…+55
Storage temperature °C -30…+70
Protection category (to IEC 60 529)
IP54 with chopped-fibre filter
IP54 with pleated filter (standard)
IP55 with pleated filter and absorber mat
IP56 with hose-proof hood
Protection category (according to NEMA)
NEMA 12 with chopped-fibre filter or pleated filter (standard)
NEMA 3, 3R, 4, 4X with hose-proof hood
Outlet filter
RAL7035 3243.300
RAL9005 3243.308
EMC RAL7035 3243.400
Tab. 8: Technical specifications Technical modifications reserved.
