Rittal 3237.700 - Page 19

Rittal Blue e+ fan-and-filter unit assembly and operating instructions 19
EN
Technical specifications
Unit Model No.
Fan-and-filter unit RAL7035 3244.700 3244.710 3244.740
Fan-and-filter unit RAL9005 3244.708 3244.718 –
EMC fan-and-filter unit RAL7035 3244.800 3244.810 –
Electrical specifications
Rated operating voltage
V
Hz
230, 1~,
50/60
115, 1~,
50/60
400, 3~
50/60
460, 3~
60
Rated current max. A 0.51/0.68 1.06/1.47 0.22/0.28
Tolerance rated operating voltage % ±10
Power consumption W 114.4/153.5 120.7/166.1 116.9/165.6
Pre-fuse T A 4 6 –
Motor circuit-breaker A – 0.2…0.4
Air throughputs (further information can be found in the characteristic curves on the Rittal homepage)
Unimpeded airflow with chopped-fibre filter m³/h 700/770
With outlet filter including chopped-fibre filter m³/h 537/587
Unimpeded airflow with pleated filter m³/h 867/910
With outlet filter including pleated filter m³/h 720/745
Other
Weight (net) kg 3.84 3.84 3.64
Fan Diagonal, capacitor motor
Diagonal,
three-phase motor
Fan bearing Ball bearing
Noise pressure level dB (A) 64/66 64/66 64/66
Operating temperature °C -30…+55
Storage temperature °C -30…+70
Protection category (to IEC 60 529)
IP54 with chopped-fibre filter
IP54 with pleated filter (standard)
IP55 with pleated filter and absorber mat
IP56 with hose-proof hood
Protection category (according to NEMA)
NEMA 12 with chopped-fibre filter or pleated filter (standard)
NEMA 3, 3R, 4, 4X with hose-proof hood
Outlet filter
RAL7035 3243.300
RAL9005 3243.308
EMC RAL7035 3243.400
Tab. 9: Technical specifications Technical modifications reserved.
