Rittal roof-mounted Blue e+ cooling unit/VX25 Blue e+ integration solution 19
4 Transport and handling
EN
The cooling unit is state of the art and built according to
recognised safety regulations. Nevertheless, improper
use can pose a threat to the life and limb of the user or
third parties, or result in possible damage to the system
and other property.
Consequently, the cooling unit must only be used prop-
erly and in a technically sound condition! Any malfunc-
tions which impair safety should be rectified immediate-
ly.
Proper use also includes the observance of the docu-
mentation provided, and compliance with the inspection
and maintenance conditions.
Rittal GmbH & Co. KG is not liable for any damage which
may result from failure to comply with the documenta-
tion provided. The same applies to failure to comply with
the valid documentation for any accessories used.
Inappropriate use may be dangerous. Examples of inap-
propriate include:
– Use of the cooling unit over long periods with the en-
closure open.
– Use of impermissible tools.
– Improper operation.
– Improper rectification of malfunctions.
– Use of accessories not approved by Rittal GmbH &
Co. KG.
– Operation in an explosion-risk area.
3.3 Supply includes
3.3.1 Blue e+ roof-mounted cooling unit scope of
supply
3.3.2 VX25 Blue e+ integration solution scope of
supply
4 Transport and handling
4.1 Delivery
The cooling unit is supplied in one packaging unit.
Check the packaging carefully for signs of damage.
Traces of oil on damaged packaging indicate a loss of
refrigerant and/or a leak in the cooling unit. Any pack-
aging damage may be the cause of a subsequent
functional failure.
4.2 Unpacking
Remove the packaging materials from the cooling unit.
Check the cooling unit for any damage that may have
occurred during transport.
Qty. Description
1 Roof-mounted Blue e+ cooling unit, includ-
ing pleated filter
1 Shipping bag with
1 – Assembly and installation instructions
1–T-rail
4 – Threaded bolt M8 x 40 mm
4–Hex nut M8
4–Washer M8
1 – Signal connector X2
1–Connector X1
1 – Condensate hose (3 m)
1 – Hose clip
1 – Screw-in nozzles
Tab. 1: Blue e+ roof-mounted cooling unit scope of supply
1–Seal
Qty. Description
1 VX25 Blue e+ integration solution
Consisting of
1 – VX25 basic enclosure with door, roof, rear
panel, side panels, gland plates, mounting
plate (1696 x 699 mm)
1 – Integral door-operated switch
1 – Cooling module, 1.30 kW
1 – Electrical condensate evaporator
1 – Pleated filter
1 Shipping bag with
1 – Assembly and installation instructions
1 – Connector X1
1 – VX25 mounting material
Tab. 2: VX25 Blue e+ integration solution scope of supply
Note:
After unpacking, the packaging materials
must be disposed of in an environmentally
friendly way.
Note:
Damage and other faults, e.g. incomplete de-
livery, should be reported immediately, in
writing, to the shipping company and to Rittal
GmbH & Co. KG.
Qty. Description
Tab. 1: Blue e+ roof-mounted cooling unit scope of supply
