Rittal TopTherm LCP Rack CW User Manual

13 Technical specifications
EN
70 Rittal Liquid Cooling Package
Tab. 36: Technical specifications for LCP Inline flush
13.2 60 kW versions
Other information
Temperature control Linear fan control/2-way control valve
TO
Air
[°C (°F)] +6 to +35 (+43 to +95)
TS
Air
[°C (°F)] +6 to +35 (+43 to +95)
Noise level [dB(A)]
(Open air above reflective flooring, distance 1 m)
77
Technical specifications
Technical specifications
Description/Model No. TopTherm LCP Rack 60 CW / 3311.268
Description/Model No. TopTherm LCP Inline 60 CW / 3311.568
Dimensions and weight
Dimensions width x height x depth (mm) 300 x 2000 x 1200
Usable U 42
Weight, max. [kg] 240
Electrical connection
Type of electrical connection Connector
Rated voltage [V, Hz] 208/2~ 50/60 230/1~ 50/60
Rated current [A] (4 fans) 9 8.1
Max. current [A] (6 fans) 13.5 12.3
Pre-fuse [A] (6 fans) 20 20
Duty cycle [%] 100
Protection category IP 20
Cooling output
Number of fans 4 5
Cooling output [kW] 40 50
Power consumption P
el
[kW] 1.87 2.2
Air throughput, max. [m
3
/h] 8000
Cooling circuit
Cooling medium Water (see Internet for specifications)
Coolant inlet temperature [°C] +15
PO
H2O
[bar (psi)] 2 to 6 (29 to 88)
PS
H2O
[bar (psi)] 6 (88)
PT
H2O
[bar (psi)] 12 (175)
Fill quantity [l] 7
Water connection 1½" outer thread
