2. SETTING
IMCB04-E10
14
(10) SL11 (SV alarm type selection)
The following instrument always set it to 0 : Alarm 1, SV alarm not provided.
• Instrument without the alarm 1 (ALM1) output.
• Instrument of the process alarm, deviation alarm, band alarm or control loop break
alarm (LBA) is used as the alarm 1 (ALM1).
The following instrument always set it to 0 : alarm 2, SV alarm not provided.
• Instrument without the alarm 2 (ALM2) output.
• Instrument of the process alarm, deviation alarm, band alarm, heater break alarm
(HBA) or control loop break alarm (LBA) is used as the alarm 2 (ALM2).
• Instrument with the Z-168 specification.
The following conditions must be satisfied in order to effectuate SV alarm.
• SL4 (Alarm 1 [ALM1] type selection, hold action selection) should be set to 0000.
The content of the SL4 setting has priority over that of the SL11 setting.
• SL5 (Alarm 2 [ALM2] type selection, hold action selection) should be set to 0000.
The content of the SL5 setting has priority over that of the SL11 setting.
Factory set value varies depending on the instrument specification.
Set value Descri
tion
0 Alarm 1
SV alarm not
rovided Alarm 1
SV alarm selection
1 Alarm 1, SV alarm provided
0 Alarm 1, SV high alarm Alarm 1, SV alarm type selection
1 Alarm 1, SV low alarm
0 Alarm 2, SV alarm not provided Alarm 2, SV alarm selection
1 Alarm 2, SV alarm provided
0 Alarm 2, SV high alarm Alarm 2, SV alarm type selection
1 Alarm 2, SV low alarm
SV alarm action type
( : Alarm set value)
SV high alarm
OFF ON
SV low alarm
ON OFF
SV
Low High
SV
Low High
