RKC INSTRUMENT CB100 Initial Setting Manual

2. SETTING
IMCB04-E10
15
2.4 List of Parameters in Initialize Code 1 (Cod = 1)
(1) SLH (Setting limiter [high limit])
Set the limiter by referring to Input range table (P.17)
 Setting method
Press the <R/S key to move the digit, then enter the high limit of the set value (SV) by pressing the UP
or DOWN key. The set value (SV) display shows the numeric value.
Factory set value varies depending on the instrument specification.
Input type Setting range
K SLL to 1372 °C (SLL to 2502 °F)
K
1
SLL to 800.0 °C
J SLL to 1200 °C (SLL to 2192 °F)
R SLL to 1769 °C (SLL to 3216 °F)
S SLL to 1769 °C (SLL to 3216 °F)
B
2
SLL to 1820 °C (SLL to 3308 °F)
E SLL to 1000 °C (SLL to 1832 °F)
N SLL to 1300 °C (SLL to 2372 °F)
T SLL to 400.0 °C (SLL to 752.0 °F)
W5Re/W26Re
2
SLL to 2320 °C (SLL to 4208 °F)
PL II SLL to 1390 °C (SLL to 2534 °F)
U
3
SLL to 600.0 °C (SLL to 999.9 °F)
Thermocouple
input (TC)
L SLL to 900 °C (SLL to 1652 °F)
Pt100 Ω (JIS/IEC)
4
SLL to 649.0 °C (SLL to 999.9 °F)
RTD input
JPt100 Ω (JIS) SLL to 649.0 °C (SLL to 999.9 °F)
0 to 5 V DC
0 to 10 V DC
5
Voltage input
1 to 5 V DC
SLL to 9999 (programmable scale)
0 to 20 mA DC
6
Current input
4 to 20 mA DC
6
SLL to 9999 (programmable scale)
SLL: Setting limiter [low limit]
1
Input type K (SLL to 800.0 °C) is selectable when Z-1038 specification is used.
2
Can’t be selected for the instrument with the modbus communication specification (Z-1021
specification).
3
Type U input is not available with Z-1038 specification.
4
IEC (International Electrotechnical Commission) is equivalent to JIS, DIN and ANSI.
5
For the 0 to 10 V DC (Z-1010 specification), no input type cannot be changed as the hardware differs.
6
For the current input specification, a resistor of 250 Ω must be connected between the input
terminals.
