RKC INSTRUMENT CD101 User Manual

5. COMMUNICATION IDENTIFIER
IMCD06-E2
31
*1: The communicable identifier differs depending on the alarm type specified in alarm 2.
− : Communication is impossible × : Communication is possible
Name Iden-
tifier
Deviation
alarm
Process
alarm
LBA
*
HBA
**
SV alarm No
alarm
Current transformer
input 1
M2 − − − × − −
Alarm 2 status
AB × × × × × −
Alarm 2 setting
A2 × × − − × −
Heater break alarm 1
setting
A3 − − − × − −
Control loop break
alarm setting
A5 − − × − − −
LBA deadband
A6 − − × − − −
As control loop break alarm, only either the alarm 1 or alarm 2 is specified.
*LBA: Control loop break alarm **HBA: Heater break alarm
*2: This is an identifier which enables communication when specifying to the Z-168 specification.
*3: The communicable identifier differs depending on the alarm type specified in alarm 1.
− : Communication is impossible × : Communication is possible
Name Iden-
tifier
Deviation
alarm
Process
alarm
LBA
*
SV alarm No
alarm
Alarm 1 status
AA × × × × −
Alarm 1 setting
A1 × × − × −
Control loop break
alarm setting
A5 − − × − −
LBA deadband
A6 − − × − −
As control loop break alarm, only either the alarm 1 or alarm 2 is specified.
*LBA: Control loop break alarm
*4: Any number other than "0" indicates errors (RAM write error, etc.) detected by the controller
self-diagnosis function. Contact your nearest RKC sales agent or RKC sales office.
The alarm type specified in alarm 2
The alarm type specified in alarm 1
