5. COMMUNICATION IDENTIFIER
IMCD06-E2
32
*5:
*6: Relay contact output: 20 sec
Voltage pulse output, Trigger output for triac driving, Triac output: 2 sec
*7: This is an identifier which enables communication at heat/cool PID action with autotuning (Water
cooling/Air cooling).
*8: Relay contact output: 20 sec Voltage pulse output, Triac output: 2 sec
*9: Details of set data lock level selection.
− : Unsettable (Data locked) ×: Settable (Data unlocked)
Set data
Set value
Alarm setting
(Alarm 1, Alarm 2)
*A
Other setting items
0
× × ×
1
× × −
2
× − ×
3
× − −
4
− × ×
5
− × −
6
− − ×
7
− − −
*A: All setting items other than set value and alarm settings (alarm 1 or alarm 2).
The set data lock function is effective only for the setting performed by key operation. Setting
items in the data lock state cannot be set by key operation, but can a always be selected via
communication.
NOTE
•In a controlled system in which ripples may be contained by the application of periodic
disturbances, use this instrument with the self-tuning function turned off.
•This is an identifier which enables communication at PID action with autotuning (Reverse
action/Direct action).
