PT0E‑0730

8

３．Operation

３−１．Checkitembeforeoperation

RX‑516or517instrument：

・Checkthatthereisnodamagefordisplayunitetc.

Filtertubewithflowmonitor：

・Checkthedirtofinsidecottonfilter.Whenitgetsdirt,replacethecottonfilterwith

newone.

・Whenwaterdropsremain,wipeitoutandchangeitwithnewone.

・Checkthattheseisnocrackordamage.

・Checkthattheseisnoloosemountonthenipple.

Gassamplinghose：

・Checkthatthereisnocrack,creekortwistontheinstrument.



３−２．Preparation

（1） Drybatteriesareputintoinstrument.

（2） Putcarryingcaseontoinstrument.

（3） Connectthe①instrument(Gasinlet)＋②Filtertubewithflowmonitor＋③Samplinghose

respectively.



 Forgassampling,3kindstipformationareavailableandchangeitaccordingtohemeasuring

environment.

  Standard: Samplinghose(1m)andgassamplingprobe

  Optional: Samplinghose(30m)withplummet

        Samplinghosewithfloatinggassamplinghead(30m)



・Connectionwithsamplinghose

 Takeknurlingpartbyfingersandpull①arrowmarkto→direction.Putittothearrow

mark②←direction.Then,releasethefingerfromtheknurlingpart.Furtherpressand

soundtick,andthen,locked.





 

Knurlingpart

①

②

③

①

②
