30
Section 3 - A Frame Installation
Drill holes 8.5mm on the appropriate place of the back rails. Use the cross rail (D) as a template.
Attach cross rail (D), using screws (12), washers (10) and nuts (13), to the back rail of the frame.
12
7
13
10
12
7
13
10
