Section 4 - In Roof Frame Installation
Important
When unpacking the in-roof frame package please check if any pieces are missing using the list
below. The pack should contain the following pieces:
No. Item Single Frame Extension
1 Angle Bracket 2 2
2 Lower Wooden Slat 1 1
3 Bottom L/H Flashing 1 N/A
4/5 Bottom Center Flashing N/A 1
6 Bottom R/H Flashing 1 N/A
7/14 Seal Strip 20x20 2.8m 2.2m
8 High Load Support Brackets 4 2
9 Wood Wedge 1 1
10 Side Seal Strip 4m 4m
11 Center Flashing N/A 1
12/13 Side Flashing 2 N/A
15 Wind Protection Rail 1 1
16 Top L/H Flashing 1 N/A
17/18 Top Center Flashing N/A 1
19 Top R/H Flashing 1 N/A
20 Nail Strips 10 2
21 Triangular Seal 1.8m 1.2m
22 Sealed Screws (4.5x35) 4 N/A
23 Wood Screws (4x30) 36 15
24 Wood Screws (5x110) 3 3
25 Sealed Screws (4x80) 2 2
26 Wood Block with Hole 2 1
