38
Section 4 - In Roof Frame Installation
Installation
Remove the tiles / slates required for installation:
2 Panel Flashing Set = 260 x 260
110cm for every further panel in the same row
Attach the lower support batten, screw the lower support batten to the rafter along where the
collectors are going to be placed. Use screws (4.5x80)
Note: These battens and screws are not included.
A = 8,5 - 12 cm
A
