RNA ESR 3000 Series User Manual

Rhein-Nadel Automation GmbH 9
VT-BA-ESR-ESM3000-EN_2021.docx / 15 March 2021
The devices are available as stand-alone add-on units or as cabinet-mounting units.
• Power switch
• Control and display panel
• Mains connection cable with grounding-type plug.
• Output socket-outlet for connection of feeder.
Sensor socket-outlet. Standard configuration includes 24 V DC sensors with PNP output.
• Control and display panel
• Electrical connection to terminals
• Screw fastening for mounting plate
Type designation
ESR 3000
ESR 3000 / 12A
ESM 3000 / 6A
ESM3000 / 16A
Mains voltage:
240 V +/- 10 %, 50/60 Hz
110 V +/- 10 %, 50/60 Hz
Output voltage:
0...205 V at 240V
0...95 V at 110V
Max. load current:
6 A
eff
12 A
eff
Max. 6 A
eff
16 A
eff
Output frequency:
35 up to 140 Hz.
Internal fuse:
6.3A mT
10A mT
6.3A mT
10A TT
Recommended *
backup protection:
16 A time-lag
min. circuit-breaker tripping characteristic ‘D’
Enabling input:
24 V DC (10-24VDC) or floating contact with internal ref. 24 VDC
Status relay
Changeover contact 250V, 1 A
Soft start delay, soft
stop delay:
0 ... 60 sec. separately adjustable
External setpoint:
0 ... 10V DC, 0(4) … 20mA
Sensor input
1 sensor input for PNP sensor
Sensor supply
24 V, DC, 100 mA
Sensor type
PNP, output
Sensor ON delay:
0 ... 60 sec. separately adjustable
Sensor OFF delay:
0 ... 60 sec. separately adjustable
Status output
Relay 1, floating changeover contact 1A, 250 VAC, 60 VDC
Valve output
24VDC, 50mA, (PNP), short-circuit-proof
-
Operating temperature
0...+45 °C
Bearing temperature
-10...+80 °C
Installation height
1000 m 0.5 % nominal current reduction per every additional 100 m
Cooling
free convection
Mounting
vibration-free
Degree of protection
IP54 (housing design)
IP20 Cabinet design
The devices are equipped with starting current damping. However, a charging current peak may occur due
to the internal capacitors condensers if several devices are powered on at the same time. Upstream fuses
or min. circuit-breakers should therefore be time-delayed.
In order to ensure the efficiency of the internal starting current damping, a waiting time of 5 seconds has to
be observed after switching off the operating voltage until switching it on again.
Design
3.1. Add-on device
3.2. Cabinet-mounted device
Technical data
