DMX protocol
Mode/Channel
1
DMX Value
Function
Type of
control
40-44 Pan/Tilt mode: Speed step
45-49 Pan/Tilt mode: Time step
50-54 Blackout while pan/tilt moving: On step
55-59 Blackout while pan/tilt moving: Off step
60-64 Blackout while gobo wheels moving: On step
65-69 Blackout while gobo wheels moving: Off step
70-74 Blackout while colour wheels moving: On step
75-79 Blackout while colour wheels moving: Off step
80-84
Fans mode: Auto
step
85-89
Fans mode: High
step
90-94
Reserved
95-99
Dimmer curve: Super Square Law
step
100-104
Focus Tracking: On
step
105-109
Focus Tracking: Off
step
110-114
Dimmer curve: Square law
step
115-119
Dimmer curve: Linear
step
120-124 Parking position: On step
125-129 Parking position: Off step
To activate following functions, stop in DMX value for at least 3 seconds.
130 - 139 Total Fixture reset (except pan/tilt) step
140 - 149 Pan/Tilt reset step
150 - 159 Colour system reset step
160 - 169 Gobo wheels/effect wheel reset step
170 - 179 Reserved
180 - 189 Zoom/focus/frost/prisms reset step
190 - 199 Iris /framing shutters reset step
200 - 209 Total fixture reset (including pan/tilt) step
210 - 218 Reserved
The following three commands define transition from gobo
rotation to gobo indexing:
219 - 220 Gobo indexing: Maximum speed and shortcut step
221 - 222 Gobo indexing: Follow speed and direction step
223 - 224 Gobo indexing: Maximum speed and follow direction step
The following RoboSpot related commands are only applicable when the
RoboSpot is connected:
225 - 229 RoboSpot enabled step
230 - 234 RoboSpot disabled - except handle faders and pan/tilt step
235 - 239 RoboSpot fully disabled step
240 Disabled "Quiet mode" step
241 - 255 Quiet mode - fan noise control from min. to max. proportional
7
Factory display menu setting: 600Hz
Select PWM output frequency of LEDs. Selected PWM frequency can be
fine adjusted in 127 steps up/down around selected PWM frequency on
the channel below. Corresponding menu item (Frequency Setup) is
temporarily overridden.
0-4
PWM frequency from Display menu (fixture utilizes PWM
step
frequency set in the display menu item Frequency Setup).
5-9 300 Hz step
