DMX protocol
Mode/Channel
1
DMX Value
Function
Type of
control
55-59 Gobo 6 step
Shaking gobos from slow to fast
Index - set indexing on channel 27
60-71 Gobo 1 proportional
72-83 Gobo 2 proportional
84-95 Gobo 3 proportional
96-106 Gobo 4 proportional
107-118 Gobo 5 proportional
119-129 Gobo 6 proportional
Shaking gobos from slow to fast
Rotation - set rotation on channel 27
130-141 Gobo 1 proportional
142-153 Gobo 2 proportional
154-165 Gobo 3 proportional
166-176 Gobo 4 proportional
177-188 Gobo 5 proportional
189-199 Gobo 6 proportional
200 - 201 Open/hole step
202 - 222 Forwards gobo wheel rotation from fast to slow proportional
223 - 243 Backwards gobo wheel rotation from slow to fast proportional
244 - 249 Random gobo selection by audio control step
(Set microphone sensitivity in menu „Personality”)
250 - 255 Auto random gobo selection from fast to slow proportional
27
Rot. Gobo 1 indexing and rotation
Gobo indexing - set position on channel 26
0 - 255 Gobo indexing proportional
Gobo rotation - set position on channel 26
0 No rotation step
1 - 127 Forwards gobo rotation from fast to slow proportional
128 No rotation (128=default) step
129 - 255 Backwards gobo rotation from slow to fast proportional
28
Rot. Gobo 1 indexing/rotation - fine
0-255 Fine indexing/rotation (0=default) proportional
29
Index - set indexing on channel 30
0-4 Open/hole (0=default) step
5-8 Gobo 1 step
9-13 Gobo 2 step
14-17 Gobo 3 step
18-22 Gobo 4 step
23-26 Gobo 5 step
27-31 Gobo 6 step
Rotation - set rotation on channel 30
32-35 Gobo 1 step
36-40 Gobo 2 step
41-44 Gobo 3 step
45-49 Gobo 4 step
50-54 Gobo 5 step
