DMX protocol
Mode/Channel
1
DMX Value
Function
Type of
control
55-59 Gobo 6 step
Shaking gobos from slow to fast
Index - set indexing on channel 30
60-71 Gobo 1 proportional
72-83 Gobo 2 proportional
84-95 Gobo 3 proportional
96-106 Gobo 4 proportional
107-118 Gobo 5 proportional
119-129 Gobo 6 proportional
Shaking gobos from slow to fast
Rotation - set rotation on channel 30
130-141 Gobo 1 proportional
142-153 Gobo 2 proportional
154-165 Gobo 3 proportional
166-176 Gobo 4 proportional
177-188 Gobo 5 proportional
189-199 Gobo 6 proportional
200 - 201 Open/hole step
202 - 222 Forwards gobo wheel rotation from fast to slow proportional
223 - 243 Backwards gobo wheel rotation from slow to fast proportional
244 - 249 Random gobo selection by audio control step
(Set microphone sensitivity in menu „Personality”)
250 - 255 Auto random gobo selection from fast to slow proportional
30
Rot. Gobo 2 indexing and rotation
Gobo indexing - set position on channel 29
0 - 255 Gobo indexing proportional
Gobo rotation - set position on channel 29
0 No rotation step
1 - 127 Forwards gobo rotation from fast to slow proportional
128 No rotation (128=default) step
129 - 255 Backwards gobo rotation from slow to fast proportional
31
Rot. Gobo 2 indexing/rotation - fine
0-255 Fine indexing/rotation (0=default) proportional
32
0 - 19 Open position - hole (0=default) step
20 - 73 Prism 1 indexing step
74-127 Prism 1 rotation step
Prism 1 /gobo macros
The following channels are blocked: Prism 1, Prism 1 indexing/ rotation,
Rotating gobo 1/2 wheel, Rot. Gobo 1/2 indexing and rotation, Rot. Gobo
1/2 fine rotation.
128 - 135 Macro 1 step
136 - 143 Macro 2 step
144 - 151 Macro 3 step
152 - 159 Macro 4 step
160 - 167 Macro 5 step
168 - 175 Macro 6 step
176 - 183 Macro 7 step
