DMX protocol
Mode/Channel
1
DMX Value
Function
Type of
control
184 - 191 Macro 8 step
192 - 199 Macro 9 step
200 - 207 Macro 10 step
208 - 215 Macro 11 step
216 - 223 Macro 12 step
224 - 231 Macro 13 step
232 - 239 Macro 14 step
240 - 247 Macro 15 step
248 - 255 Macro 16 step
33
Prism 1 indexing/rotation
Prism 1 indexing - set position on channel 32
0 - 255 Prism 1 indexing proportional
Prism 1 rotation - set position on channel 32
0 No rotation step
1 - 127 Forwards prism rotation from fast to slow proportional
128 No rotation (128=default) step
129-255 Backwards prism rotation from slow to fast proportional
34
Prism 2 (6-facet circular)
0 - 19 Open position - hole (0=default) step
20-127 Prism 2 rotation step
Prism 2 /gobo macros
The following channels are blocked: Prism 2, Prism 2 rotation, Rotating
gobo wheel 1/2, Rot. Gobo 1/2 indexing and rotation, Rot. Gobos 1/2 fine
rotation.
128 - 135 Macro 1 step
136 - 143 Macro 2 step
144 - 151 Macro 3 step
152 - 159 Macro 4 step
160 - 167 Macro 5 step
168 - 175 Macro 6 step
176 - 183 Macro 7 step
184 - 191 Macro 8 step
192 - 199 Macro 9 step
200 - 207 Macro 10 step
208 - 215 Macro 11 step
216 - 223 Macro 12 step
224 - 231 Macro 13 step
232 - 239 Macro 14 step
240 - 247 Macro 15 step
248 - 255 Macro 16 step
35
Prism 2 rotation
0 No rotation step
1 - 127 Forwards prism rotation from fast to slow proportional
128 No rotation (128=default) step
129-255 Backwards prism rotation from slow to fast proportional
36
Frost
0 Open (0=default) step
Light Frost
