DMX protocol
Mode/Channel
1
DMX Value
Function
Type of
control
1-50 Light Frost from 0% to 100% proportional
51-53 100% Light Frost step
54-63 Pulse closing from slow to fast proportional
64-73 Pulse opening from fast to slow proportional
74-83 Ramping from fast to slow proportional
84-86 Open step
Medium Frost
87-136 Medium Frost from 0% to 100% proportional
137-139 100% Medium Frost step
140-149 Pulse closing from slow to fast proportional
150-159 Pulse opening from fast to slow proportional
160-169 Ramping from fast to slow proportional
170-255 Open step
37
Iris
0 Open (0=default) step
1 - 179 From max. diameter to min. diameter proportional
180 - 191 Closed step
Pulse effects with Iris blackout
192 -219 Pulse opening from slow to fast proportional
220 - 247 Pulse closing from fast to slow proportional
248 - 249 Random pulse opening (fast) step
250 - 251 Random pulse opening (slow) step
252 - 253 Random pulse closing (fast) step
254 - 255 Random pulse closing (slow) step
38
Iris - fine
0 - 255 Fine iris movement (0=default) proportional
39
Zoom
0 - 255 Zoom from max. to min. beam angle (128=default) proportional
40
Zoom - fine
0-255 Fine zooming (0=default) proportional
41
Focus
0 - 255 Continuous adjustment from far to near (128=default) proportional
42
Focus - fine
0- 255 Fine focusing (0=default) proportional
43 Framing shutters module rotation
0-127 Rotation from right (0°) to 60° proportional
128 Centre (128=default) step
129-255 Rotation from 60° to left (120°) proportional
44 Framing shutter 1- movement
0-255 Movement from Outward to Inward (0=default) proportional
45 Framing shutter 1- swivelling
0-127 Swivelling from -30 degrees towards 0 degrees proportional
128 0 degrees (128=default) step
129-255 Swivelling from 0 degrees to +30 degrees proportional
46 Framing shutter 2- movement
0-255 Movement from Outward to Inward (0=default) proportional
47 Framing shutter 2- swivelling
0-127 Swivelling from -30 degrees towards 0 degrees proportional
