DMX protocol
Mode/Channel
1
DMX Value
Function
Type of
control
128 0 degrees (128=default) step
129-255 Swivelling from 0 degrees to +30 degrees proportional
48 Framing shutter 3 movement
0-255 Movement from Outward to Inward (0=default) proportional
49 Framing shutter 3- swivelling
0-127 Swivelling from -30 degrees towards 0 degrees proportional
128 0 degrees (128=default) step
129-255 Swivelling from 0 degrees to +30 degrees proportional
50 Framing shutter 4 movement
0-255 Movement from Outward to Inward (0=default) proportional
51 Framing shutter 4- swivelling
0-127 Swivelling from -30 degrees towards 0 degrees proportional
128 0 degrees (128=default) step
129-255 Swivelling from 0 degrees to +30 degrees proportional
52
0 - 31 Shutter closed step
32 - 63 Shutter open (32=default) step
64 - 95 Strobe-effect from slow to fast proportional
96 - 127 Shutter open step
128 - 143 Opening pulse in sequences from slow to fast proportional
144 - 159 Closing pulse in sequences from fast to slow proportional
160 - 191 Shutter open step
192 - 223 Random strobe-effect from slow to fast proportional
224 - 255 Shutter open step
53
0 - 255 Dimmer intensity from 0% to 100% (0=default) proportional
54
0 - 255 Fine dimming (0=default) proportional
