NO. Partname DisassemblingInstructions
4
COVER,ENGINE
COVER,PLUG
GUARD,OIL
STARTER
(1) RemovetheGUARD,OIL.
(2) RemovetheSTARTER.
(3) RemovetheCOVER,ENGINE.
NOTICE:BecarefulnottoloosetheGUARD,OILorCOVER,PLUG.
5
TANK,FUEL
(1) Removethefueltube.
NOTICE:Thefuelwillspoutifthefueltubeisremovedwiththefueltankfilledwithfuel.
(2) RemovetheTANK,FUEL.


SCREW
M6*12W,SW (2PCS)
TANK
,FUEL

TAPPINGSCREW
5*16(4PCS)
COVER
,ENGINE

COVER,PLUG

STARTER

GUARD
,OIL

SCREW
M5*20(3PCS)
