Robin FL-H7500 - Page 12

11
  
NO. Partname DisassemblingInstructions
6
LEVER
(CONTROLCABLE
,WIRING)

Forinstructionsonthelever
disassembling,seepages14
and15.
(1) Disconnectthewiring. 
(2) DisconnecttheCONTROLCABLEfromtheCARBURETOR.
7
CASE,AIRCLEANER
〜CASE,VOLUTE
(1) RemovetheCASE,AIRCLEANER.
(2) Disconnectthetwotubesconnectedtotheaircleaner.

(1)

(2)

SCREW
M5*16W,SW (4PCS)
ROCKERCOVER〜AIRCLEANER
AIRCLEANER〜CYLINDER
PLATE,SEPARETOR
PLATE,CHECKVALVE
CHECKVALVE
CHECKVALVE(1)
7-1InstructionsontheCASE,AIRCLEANERdisassembling.
(1) RemovethePLATE,SEPARATOR.
(2) RemovethePLATE,CHECKVALVE(withtheCHECKVALVE).
(3) RemovetheCHECKVALVE(1).
NOTICE:Becarefulnottoloosetheparts.HandletheCHECKVALVE
withcarenottodamageit.
