15
  
NO. Partname DisassemblingInstructions
 
6-1

LEVER
CASE2,LEVERASSY

LEVER2,THROTTLE

(2) RemovetheLEVER2,THROTTLEfromtheCASE2,LEVERASSY.


LEVER2,THROTTLE

SELFROCKNUT
M6(1PCS)
SOCKETHEADBOLT
M6*14(1PCS)
WASHER

WAVEWASHER

