14
  
NO. Partname DisassemblingInstructions
 
6-1

LEVER
CASE1,LEVER
CASE2,LEVERASSY



(1) RemovetheCASE1,LEVERandCASE2,LEVERASSY. 



TAPPINGSCREW
4*16(5PCS)
CASE2,LEVER
ASSY

NUT
M5(1PCS)
SCREW
M5*25(1PCS)
CASE1,
LEVER

