NO. Partname AssemblingInstructions
 
5
FRAME
CUSHION


6
FRAME
 〜NET
(1)InstalltheNETontheFRAMEbyscrewingtheSCREWRIVETS.
CUSHION

RIVETROCK
（
6PCS
）

SCREW
M5*16W,SW MEC(2PCS)
Tighteningtorque25   ㎏ｆ･㎝
+15

0
FRANGENUT
M6（2 ヶ）
Tighteningtorque 25    ㎏ｆ･㎝
+15

0
SCREWRIVETS

NET

UpsideNET

TightentheSCREWwiththetighteningtorqueas
shownintheprecedingpageaftertheFRAME
assembling.
FRAME

