Robin FL-H7500 - Page 21

20
  
NO. Partname AssemblingInstructions
 
7 CASE,AIRCLEANER
         〜TUBE
(1) Installthetubescorrectlyasshowninthephotographsbelow.Applysiliconoroiloverthe
insertingpartofthetubesbeforeinstallingthem,ifnecessary.


8 CASE,AIRCLEANER
〜CASE,VOLUTE

SCREW
M5*16W,SW (4PCS)
Tighteningtorque25   ㎏ｆ･㎝

+15

0
ROCKERCOVER
〜
AIRCLEANER

AIRCLEANER
〜
CYLINDER

Tubeslayout
