Robin FL-H7500 - Page 22

21
  
NO. Partname AssemblingInstructions
9
LEVER
(CONTROLCABLE
&WIRING)
(1) InserttheinnercableoftheCONTROLCABLEintotheCARBURETORSadjustingboltand
fititintheSWIVELgroove.
(2) FittheoutercableoftheCONTROLCABLEand high-tensioncodeinthegrooveofthe
CASE2,VOLUTE.(TheCONTROLCABLEshouldbeunderthehigh-tensioncode.)
(3) ConnecttheWIRESfromtheLEVERandtheonesoftheCOIL,andholdtheCONTROL
CABLEandconnectedwireusingtheclampoftheCASE2,VOLUTE.
(4) FixthecabletotheELBOWwiththetie-wrap.
10
TANK,FUEL

SCREW
M6*12W,SW (2PCS)
Tighteningtorque25   ㎏ｆ･㎝

+10

−5

TANK
,FUEL

(1)

(3)

Tie
-
wrap

Holdtheclamp

(2)

CONTROLCABLE

High
-
tension
code

(4)

Be sure to install the
fueltube.
