23
  
NO. Partname AssemblingInstructions
12
ELEMENT
COVER,AIRCLEANER
KNOBBOLT
DUCT
HOSECLAMP
(1) TheKNOBBOLTSmaybescrewedwiththehand. 
(2) ThetighteningtorqueoftheHOSECLAMPboltshouldbe15kgf･cm.
(3) BecarefulthattheDUCTfittedinisnotcoveredwiththeCOVER,AIRCLEANER.


KNOBBOLT
COVER,AIRCLEANER

ELEMENT
DUCT

HOSECLAMP

HOSECLAMP

Fitinthehoseclamp
withtheboltdirected
upward.
AfterfittingintheDUCT,pullit
inthedirectionofthearrow
shownbelowuntilitstopsso
thattheDUCTfittedinisnot
becoveredwiththe
COVER,AIRCLEANER.
(2)
