24
  
NO. Partname AssemblingInstructions
13-1
LEVER
CASE2,LEVER
LEVER2,THROTTLE
(1) FitthethrottleleverintheCASE2,LEVERusingtheSOCKETHEADBOLT,WAVEWASHER,
WASHER,andSELFLOCKNUT.
13-2
CASE1,LEVER
LEVER1,THROTTLE
CONTROLCABLE
SWITCH
TORSIONSPRING
(1) LettheSWITCHleadwireandCONTROLCABLEintotheTUBE,CABLEinadvance.
(2) FittheSWITCHleadwireinthegrooveoftheCASE1,LEVER.
(3) Fittheendfittingofthecontrolinnercableinthehole(c)oftheLEVER1,THROTTLE.Fitthe
TORSIONSPRINGoverthecylindricalhollowcolumn(e)andfittheLEVER1,THROTTLE
hole(d)overthecylindricalcolumn(e).

LEVER2,THROTTLE
SELFLOCKNUT
M6(1PCS)
WASHER
WAVEWASHER
SOCKETHEADBOLT
M6*14(1PCS)
Tighteningtorque15   ㎏ｆ･㎝

+5
0
SWITCH
LEADWIRE
CASE1,LEVER
TUBECABLE
LEVER1,THROTTLE
CONTROLCABLE
Afterscrewingthebolt,checkif
theLEVER2,THROTTLEcanbe
smoothlymoved
(c)

(d)
(e)
BecarefulabouttheTORSION
SPRINGdirection.
