RoboBuilder RQ-110 - RIGHT ARM Assembly

29
2.5 RIGHT ARM Assembly
3*6 L type Frameⅹ2 Smart Servoⅹ2(ID14, ID15) ‘U’ Frame x 2
Joint Frameⅹ1 3s rivetⅹ1 2s rivetⅹ12
Bolt (B27) x 4, NUT x 4
STEP1. Make “Hand” part by using the two “3*6 L type Frame” and “2s rivets” as shown in the below.
Becareful with “3*6 L type Frame” part direction because the both sides are not same.
