RoboBuilder RQ-110 - Page 39

39
STEP7. Connect Front Horn with ID13. Check the Front Horn and ID00 mark position.
- Smart servo mark position is 1 o’clock while Front Horn mark position is 12 o’clock as shown in the below.
STEP8. Connect Joint Frame with Front Horn by using 2s rivets as shown in the below.
