Robotiq Hand-E Gripper Instruction Manual
3.2. Required Tools and Equipment
The following tools are required to install the Hand-E Gripper:
l 4 mm hex key to mount the gripper onto its coupling or the I/O Coupling.
l Metric hex key according to your coupling to mount the coupling onto the robot.
Optional tools if installing fingertip/holder kits: HND-FIN-ALU-KIT, HND-TIP-VGR-KIT or HND-TIP-HLD-KIT
l 2,5 mm hex key
The gripper needs to be supplied by a DC voltage source. This power supply is not included with the gripper. Required power
supply must match the Robotiq device. The following table shows the specifications with regards to the power supply required to
operate the gripper and the optional Robotiq Controller.
SPECIFICATION VALUE
Output voltage 24 V DC ±10%
Output current 1 A
Overcurrent
Recommended power supply with internal protection, otherwise fusing
is required.
2 A fuse at 25°C [77°F]
1
Table 3-1: Hand-E power supply requirements.
Info
1
Suggested fuse is a: Phoenix Contact # 0916605 2 A thermal, use AWG #20 wiring.
Warning
If your power supply could exceed the specified regulation, over-voltage protection is required.
Robotiq recommends the use of the following power supplies:
l For the 1A output current: TDK-Lambda DPP Series, 100W Single Output DIN Rail Mount Power Supply: DPP30-24.
Tip
Optional Robotiq Universal Controller can use the same power supply.
