Robur Next-R - Page 12

Features and technical data
12
1
1.2.1.5 R60
Figure1.5 Unit dimensions
1 Flue gas exhaust
2 Combustion air inlet
3 Power supply cables input
4 Gas connection 3/4" F
5 Thermoformed door
6 Limit thermostat
7 Flue gas exhaust blind cover, alternative to the rear one (1)
8 Blind cover for access to the fan thermostat
(*) Holes for xing to the support bracket
731
593
435
777
1119
900
860
210
475
80
80
340
690
383
3
4
12
432 234234
810 (*)
405 (*)
6
5
120
7
8
76
817
