5 FIRST STARTUP
First start-up entails checking/setting up the com-
bustion parameters and may exclusively be carried
out by a Robur TAC. NEITHER the user NOR the in-
stallation technician is authorised to perform such
operations, under penalty of voiding the warranty.
The installer is obliged to carry out preliminary
checks described in Paragraph 5.1 p.42 .
5.1 PRELIMINARY CHECKS
Paragraph dedicated to the installer.
5.1.1 Preliminary checks for rst start-up
Upon completing installation, before contacting the TAC
the installer must check:
▶ Electrical and gas systems suitable for the required ca-
pacities and equipped with all safety and control de-
vices required by the regulations in force.
▶ Absence of leaks in the gas system.
▶ Type of gas for which the appliance is designed (natu-
ral gas, LPG or other gas).
▶ Supply gas pressure complying with the values of
Table 3.1 p.29 , with max tolerance ±15%.
▶ Correct operation of the ue exhaust duct.
▶ Combustion air feed and ue gas exhaust correctly
carried out according to the regulations in force.
▶ Power supply mains complying with the appliance's
rating plate data.
▶ Appliance correctly installed, according to the manu-
facturer's instructions.
▶ System installed in a workmanlike manner, according
to national and local regulations.
5.1.2 Abnormal or hazardous installation
situations
Should any abnormal or hazardous installation situations
be found, the TAC shall not perform rst start-up and the
appliance shall not be commissioned.
These situations may be:
▶ Failed compliance with minimum clearances.
▶ Insucient distance from combustible materials.
▶ Conditions that do not warrant access and mainte-
nance in safety.
▶ Appliance switched on/o with the main switch, in-
stead of the provided control device.
▶ Appliance defects or faults caused during transport or
installation.
▶ Gas smell.
▶ Non-compliant mains gas pressure.
▶ Non-compliant ue gas exhaust.
▶ All situations that may involve operation abnormali-
ties or are potentially hazardous.
5.1.3 Non-compliant system and corrective
actions
Should the TAC nd any non conformities, the user/install-
er is bound to perform any corrective procedures required
by the TAC.
After performing the remedial actions (the installer's re-
sponsibility), if the TAC deems that safety and conformity
conditions are in place, rst start-up may be eected.
5.2 COMBUSTION PARAMETERS CHECK
Paragraph reserved exclusively to TACs.
The gas unit heater is supplied with the gas valve
already calibrated with respect to the fuel indi-
cated on the sticker next to the gas connection.
Therefore, during the commissioning, only the CO
2
value must be checked and, only if the check is not
successful, or after a gas changeover, the complete
check procedure must be carried out.
The CO
2
value should be checked with the thermo-
formed door closed, while the gas valve should be
adjusted with the thermoformed door open.
If a dierential pressure gauge is used, it is neces-
sary to connect the pressure intake A of the gas
valve to the + (positive) port of the pressure gauge.
5.2.1 R15/R20/R30/R40/R50
The simple check of CO
2
values corresponds to
steps 8 to 13 of the procedure below, after turning
on the unit. If the check is not successful, the com-
plete procedure must be carried out.
Figure 5.1 p.43
1. If the appliance is running, switch it o with the appli-
cable control system.
2. Open the thermoformed door.
3. Remove the cap over the oset adjustment screw (C)
of the gas valve.
