Robustel GoRugged M1000 User Manual

Robustel GoRugged M1000 User Guide
RT_UG_M1000 Standard_v.2.0.0 20.12.2013 11 / 83
Confidential
Serial Interface
 Number of Ports: 1 x DB9 Female
 Serial Standards: RS232 and RS485
 ESD Protection: ±15KV
 Baudrate: 8N1, 1200bps to 115200bps
 RS-232: TxD, RxD, RTS, CTS, GND
 RS-485: Data+ (A), Data- (B), GND
Digital Input
 Type: Dry Contact, DI or event counter
 Dry Contact: On: open, Off: short to GND
 Isolation: 3K VDC or 2K Vrms
 Counter Frequency: 900 Hz
 Digital Filtering Time Interval: Software selectable
Digital Output
 Type: Sink, DO or pulse output
 Pulse Output Frequency: 1 kHz
 Isolation: 3K VDC or 2K Vrms
System
 LED Indicators: PWR, RUN, NET and 3 level RSSI
 Real Time Clock: Built-in RTC with button battery
 Watchdog and Timer: Built-in watchdog and timer
Power Supply and Consumption
 Power Supply Interface: 2-pin 5mm pluggable terminal block
 Input Voltage: 9 to 36 VDC
 Power Consumption: Idle: 50-60 mA @ 12 V
Data Link: 100 to 200 mA (peak) @ 12 V
Physical Characteristics
 Housing & Weight: Metal, 300g
 Dimension(L x W x H): 102 x 71 x 29 mm
 Installation: 35mm Din-Rail or wall mounting or desktop
