Your New System
The Accu‑Chek Guide Meter
1
4
5
3
7
6
8
Front View Back View Side View
1. Display
Shows results, messages, and test
results stored in memory.
2. Back Button
Returns to a previous display or field.
3. Up Arrow and Down Arrow Buttons
Press to move between menu options or
to increase or decrease numbers.
4. Power/Set/OK Button
Turns meter on or o and sets options.
5. Test Strip Slot with Light
Insert test strip here.
6. Battery Door
Flip open to replace batteries.
7. Micro USB Port
Transfers data from meter to a computer
(PC).
8. Test Strip Ejector
Press to remove test strip.
