Rockwell Automation Publication 1766-UM001O-EN-P - September 2021 139
Appendix A Specifications
Operating altitude 2000 m
(656
1 ft)
Vibration
Operating: 10...500 Hz, 5 g, 0.030 in. max. peak-to-peak, 2 hours per ax
is
Relay Operation: 1.5 g
Shock
Operating: 30G panel mounted, 3 pulses per axis
Relay Operation: 7 g
Non-Operating: 50 g panel mounted, 3 pulses per axis
(40G DIN Rail mounted)
(1) For module-specific operating temperature range, see the Installation Instructions for the specific module.
General Specifications – Digital I/O Modules (Continued)
Specification Value
Environmental Specifications
Attribute Value
Emissions IEC 61000-6-4
ESD immunity
IEC 61000-4-2:
6 kV contact discharges
8 kV air discharges
Radiated RF immunity
IEC 61000-4-3:
10V/m with 1 kHz sine-wave 80% AM from 80…1000 MHz
3V/m with 1 kHz sine-wave 80% AM from 1.4…2.0 GHz
1V/m with 1 kHz sine-wave 80% AM from 2.0…2.7 GHz
EFT/B immunity
IEC 61000-4-4:
±2 kV @ 5 kHz on signal ports
Surge transient immunity
IEC 61000-4-5:
±1kV line-line(DM) and ±2kV line-earth(CM) on signal ports
Conducted RF immunity
IEC 61000-4-6:
10V rms with 1 Hz sine-wave 80% AM from 150 kHz…80 MHz
Certifications
Certification (when product is marked)
(1)
Value
UL UL Listed for Class I, Division 2 Group A, B, C, D Hazardous Locations
c-UL UL Listed for Class I, Division 2 Group A, B, C, D Hazardous Locations, certified for Canada.
CE
European Union 2014/30/EU EMC Directive, compliant with:
EN 61000-6-2; Industrial Immunity
EN 61000-6-4; Industrial Emissions
EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
European Union 2014/35/EU LVD, compliant with:
EN 61131-2; Programmable Controllers (Clause 11)
RCM
Australian Radiocommunications Act, compliant with:
AS/NZS CISPR 11; Industrial Emissions
EAC Russian Customs Union TR CU 020/2011 EMC Technical Regulation
KC
Korean Registration of Broadcasting and Communications Equipment, compliant with:
Article 58-2 of Radio Waves Act, Clause 3
(1) See the Product Certification link at rok.auto/certifications for Declaration of Conformity, Certificates, and other certification details.
Input Specifications – 1762-IA8, 1762-IQ8, 1762-IQ16, 1762-IQ32T, 1762-IQ8OW6
Specification 1762-IA8 1762-IQ8 1762-IQ16 1762-IQ32T 1762-IQ8OW6
Shipping weight, approx.
(with carton)
209 g (0.46 lbs.) 200 g (0.44 lbs.) 230 g (0.51 lbs.) 200g (0.44 lbs.) 280g (0.62 lbs.)
Voltage category 100/120V AC
24V DC (sink/source)
(1)
24V DC (sink/source)
(1)
24V DC
(sink/source)
(1)
24V DC (sink/source)
(1)
Operating voltage range 79V AC…132V AC at 47 Hz…63 Hz
10…30V DC at 30 °C (86 °F)
10…26.4V DC at
55 °C (131 °F)
10…30V DC
10…26.4V DC
(3)(2)
10…30V DC (24 points) at
30 °C (86 °F)
10…26.4V DC (23 points) at
60 °C (140 °F)
10…30V DC at 30 °C (86 °F)
10…26.4V DC at 65 °C (149 °F)
Number of inputs 8 8 16 32 8
Bus current draw, max. 50 mA at 5V DC (0.25W) 50 mA at 5V DC (0.25W)
70 mA at 5V DC (0.35W)
(3)
170 mA at 5V DC
0 mA at 24V DC
110 mA at 5V DC
80 mA at 24V DC
