Rockwell Automation Publication 1766-UM001O-EN-P - September 2021 219
Appendix F MicroLogix 1400 Distributed Network Protocol
Related Configuration File Numbers:
• 16-bit Analog Input Deadband Config File Number (In Series B and
Series C)
• 32-bit Analog Input Deadband Config File Number (In Series B and
Series C)
• Short Floating Point Analog Input Deadband Config File Number (In
Series B and Series C)
For Analog Output type data, you can configure the object flag information in
the Configuration file. The upper byte of the configuration file of these objects
is used to configure the object flag. Other bits are reserved.
Related Configuration File Numbers:
• 16-bit Analog Input Deadband Config File Number (In Series B and
Series C)
• 32-bit Analog Input Deadband Config File Number (In Series B and
Series C)
• Short Floating Point Analog Input Deadband Config File Number (In
Series B and Series C)
For Small BCD type data, you can configure Class information in the
Configuration file. The lower 2 bits in each element of the Configuration files
are the configuration of Class information to the relevant objects. P0 bit in the
first element is for excluding Small BCD Data from Class 0 poll responses.
Other bits are reserved.
Related Configuration File Numbers:
• Small BCD Config File Number
Word Offset Description
Element 0 Deadband for point 0
Element 1 Deadband for point 1
Element 2 Deadband for point 2
Element 3 Deadband for point 3
Element 4 Deadband for point 4
Element 5 Deadband for point 5
…
Analog Output Configuration Data File
Bit Offset 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Element 0 F7F6F5F4F3F2F1F0rrrrrrrr
Element 1 F7F6F5F4F3F2F1F0rrrrrrrr
Element 2 F7F6F5F4F3F2F1F0rrrrrrrr
Element 3 F7F6F5F4F3F2F1F0rrrrrrrr
Element 4 F7F6F5F4F3F2F1F0rrrrrrrr
Element 5 F7F6F5F4F3F2F1F0rrrrrrrr
…
r: reserved
F7…F0: Object Flags, FLAG7/FLAG6/FLAG5/LOCAL_FORCED/REMOTE_FORCED/COMM_LOST/RESTART/ONLINE
Small BCD Configuration File Data
Bit Offset 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Element 0 rrrrrrrrPOrrrrrC1C0
Element 1 rrrrrrrrrrrrrrC1C0
Element 2 rrrrrrrrrrrrrrC1C0
Element 3 rrrrrrrrrrrrrrC1C0
Element 4 rrrrrrrrrrrrrrC1C0
