Rockwell Automation Publication 1766-UM001O-EN-P - September 2021 241
Appendix F MicroLogix 1400 Distributed Network Protocol
When the Descriptor Code is selected as PTYP, the Point Addressing
parameters for the Descriptor element are replaced by 10 Point Addressing
parameters. These should be configured in the same order of the DAEL
elements in the relevant Prototypes.
BSTR = 6 0…255
2(S)
3, 9…255 (B)
7, 9…255 (N)
0…65 for S
0…255 for B, N,
0 for S, N
0…15 for B
TIME = 7 0…6
2(S)
3, 9…255 (B)
7, 9…255 (N)
9…255 (L)
0…65 for S
0…255 for B, N, L
0 for S, N, L
0…15 for B
Table 29 - Point Address Type — MicroLogix Data File (Continued)
Point Address Type Data Type Code
Maximum Data Length
(bytes)
File Number File Element File Sub-Element
