Rockwell Automation Publication 1766-UM001O-EN-P - September 2021 279
Appendix F MicroLogix 1400 Distributed Network Protocol
32 4 Analog Input Event – 16-bit with time 1 (read)
06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
32 5
Analog Input Event – Single-prec flt-pt
without time
1 (read)
06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
32 7
Analog Input Event – Single-prec flt-pt
with time
1 (read)
06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
40 0 Analog Output Status – Any Variation 1 (read)
00, 01 (start-stop)
06 (no range, or all)
40 1 Analog Output Status – 32-bit with flag
1 (read)
00, 01 (start-stop)
06 (no range, or all)
129 (response) 00, 01 (start-stop)
40 2 Analog Output Status – 16-bit with flag
1 (read)
00, 01 (start-stop)
06 (no range, or all)
129 (response) 00, 01 (start-stop)
40 3
Analog Output Status – Single-prec flt-
pt with flag
1 (read)
00, 01 (start-stop)
06 (no range, or all)
129 (response) 00, 01 (start-stop)
41 1 Analog Output – 32-bit
3 (select)
4 (operate)
5 (direct op)
6 (dir. op, no ack)
17, 27, 28 (index) 129 (response) echo of request
41 2 Analog Output – 16-bit
3 (select)
4 (operate)
5 (direct op)
6 (dir. op, no ack)
17, 27, 28 (index) 129 (response) echo of request
41 3 Analog Output – Single-prec flt-pt
3 (select)
4 (operate)
5 (direct op)
6 (dir. op, no ack)
17, 27, 28 (index) 129 (response) echo of request
50 1 Time and Date – Absolute time
1 (read) 07 (limited qty = 1) 129 (response)
07 (limited qty)
(qty = 1)
2 (write) 07 (limited qty = 1)
50 3
Time and Date – Absolute time at last
recorded time
2 (write) 07 (limited qty = 1)
51 1
Time and Date CTO – Absolute time,
synchronized
129 (response)
130 (unsol. resp)
07 (limited qty)
(qty = 1)
51 2
Time and Date CTO – Absolute time,
unsynchronized
129 (response)
130 (unsol. resp)
07 (limited qty)
(qty = 1)
52 2 Time Delay – Fine 129 (response)
07 (limited qty)
(qty = 1)
60 1 Class Objects – Class 0 data 1 (read) 06 (no range, or all)
60 2 Class Objects – Class 1 data
1 (read)
06 (no range, or all)
07, 08 (limited qty)
20 (enbl. unsol.)
21 (dab. unsol.)
06 (no range, or all)
60 3 Class Objects – Class 2 data 1 (read)
06 (no range, or all)
07, 08 (limited qty)
60 4 Class Objects – Class 3 data
1 (read)
06 (no range, or all)
07, 08 (limited qty)
20 (enbl. unsol.)
21 (dab. unsol.)
06 (no range, or all)
70 2 File-Control – authentication
29 (authenticate file) 5B (free format) 129 (response) 5B (free format)
70 3 File Control – file command 25 (open file) 5B (free format)
70 3 File Control – file command
27 (delete file) 5B (free format)
70 4 File Control – file command status
26 (close file) 5B (free format) 129 (response) 5B (free format)
70 4 File Control – file command status 30 (abort file) 5B (free format) 129 (response) 5B (free format)
70 5 File Control – file transport
1 (read file) 5B (free format) 129 (response) 5B (free format)
70 5 File Control – file transport
2 (write file) 5B (free format) 129 (response) 5B (free format)
70 6 File Control – file transport status 129 (response) 5B (free format)
Table 38 - Implementation Table for Series B and Series C controllers (Continued)
