34 CompactLogix Packaged Controllers
Publication 1769-IN082A-EN-P - July 2008
8. Click Finish and then click Yes.
The firmware upgrade begins.
During the firmware upgrade you see the status change as shown below.
Continue to allow the firmware upgrade to complete without interuption.
IMPORTANT
DO NOT INTERUPT THE FIRMWARE UPGRADE ONCE IT HAS BEGUN.
Interupting the firmware upgrade may result in an inoperable packaged controller.
Status
Change
Status
Change
