6 CompactLogix Packaged Controllers
Publication 1769-IN082A-EN-P - July 2008
Replacement Parts
These CompactLogix packaged controller replacement parts are available for order.
Required Tools
The only tool required for the installation of the CompactLogix packaged controller
is a medium-sized Phillips-head screwdriver.
Required System Components
Use these system components with your CompactLogix packaged controller.
Catalog No. Description Compatible Packaged Controllers
1769-BA CompactLogix packaged controller
battery
1769-L23E-QB1B, 1769-L23E-QBFC1B, and
1769-L23-QBFC1B
1769-ECR Compact right end cap 1769-L23E-QB1B, 1769-L23E-QBFC1B, and
1769-L23-QBFC1B
1769-RDQB CompactLogix packaged controller door
1769-L23E-QB1B
1769-RDQBFC CompactLogix packaged controller door 1769-L23E-QBFC1B and 1769-L23-QBFC1B
Software Component Version
RSLogix 5000 17.00 or later
RSLinx Classic
2.52
(1)
(1)
You may use an earlier version of RSLinx software, however, if you do so,
you must download and install the EDS files specific to these controllers.
Also, if you are using Windows Vista, you must use RSLinx Classic
software, version 2.54.
