Rockwell Automation Publication 2198-UM005C-EN-P - February 2022 51
Chapter 4
Connector Data and Feature Descriptions
This chapter illustrates drive connectors and indicators, including connector
pinouts, and provides descriptions for Kinetix® 5300 drive features.
Topic Page
Kinetix 5300 Connector Data 52
Understand Control Signal Specifications 56
Feedback Specifications 58
Safe Torque Off Safety Features 65
